Zenty ZT-162 IP Controller for AV Over IP System

Zenty

Zenty ZT-162 IP Controller for AV Over IP System
$540.00

25% Discount. Apply Code 25percentOff at Checkout!

Part Number:
ZT-162
Condition:
New
Availability:
In Stock
1:
IP Control via LAN
2:
Features Two Ethernet Ports
3:
Supports Matrix Switching
4:
Free Z-Net iPad Control App
5:
Free USA Shipping
6:
International Shipping w/Wire Transfer
7:
Hassle-free Warranty
8:
5-Year Zenty Warranty
9:
Free Returns within 60 Days
10:
Lifetime Technical Support
11:
Save 5% with Wire Transfer or Check

This Zenty ZT-162 IP Controller for AV Over IP System is an IP control box that is used as an A/V control device for controlling, configuring and managing encoders and decoders on the local area network. It integrates two Ethernet ports and two RS232 ports, offering integration-friendly control features - LAN (WebGUI & Telnet). It also can be used with a third-party controller to provide a simple, flexible control and management options. IP controller can automatically search and display encoders and decoders. It is designed to be compatible with the configuration file from PC configurator (HDMI over IP Console) and use the imported configuration file to perform operations on encoders and decoders such as matrix and video wall.

Zenty ZT-162 IP Controller for AV Over IP System Features:

  • IP control via LAN (Web GUI & Telnet) and a third-party controller
  • Features two Ethernet ports and two RS232 ports
  • Discover encoders and decoders automatically
  • Supports matrix switching between encoders and decoders
  • Compatible with the configuration file from PC configurator to quickly perform operations on encoders and decoders, such as matrix and video wall
  • Web configuration page

Why not buy this Zenty ZT-162 IP Controller for AV Over IP System from HDTV Supply today?

Zenty ZT-162 IP Controller for AV Over IP System Specification:

  • Technical:
    • I/O Connections: 1 x LAN (AV/PoE) (10/100Mbps); 1 x LAN (C) (10/100Mbps); 2 x RS232
    • LED: 1 x Status LED; 1 x Power LED
    • Button(s): 1 x Reset Button
    • Control Method: LAN (WebGUI & Telnet), RS232, and a third-party controller
  • General:
    • Power Supply: 12V/DC 1A
    • Power Consumption: 4.5W Max (without outputting 12V 0.5A using RS232 port); 10.5W Max (with outputting 12V 0.5A using RS232 port)
    • Operating Temperature: 32°F ~ 113°F (0°C ~ 45°C)
    • Operating Humidity: 10% ~ 90%, non-condensing
    • Storage Temperature: -4°F ~ 140°F (-20°C ~ 70°C)
    • Storage Humidity: 10% ~ 90%, non-condensing
    • Surge Protection: Voltage: ±1000V (Tested ten times for positive and negative voltages)
    • ESD Protection: Human body model: ±8kV (air-gap discharge); ±4kV (contact discharge)
    • Product Dimension (W x H x D): 93.2mm x 26mm x 138.7mm / 3.67” x 1.02” x 5.46”
    • Case Dimension (W x H x D): 170mm x 80mm x 250mm / 6.69” x 3.15” x 9.84”

Why not buy this Zenty ZT-162 IP Controller for AV Over IP System from HDTV Supply today?

Zenty ZT-162 User Manual
