8x8 HDMI Matrix Switcher w/8 x Cat5/Cat6 Receivers to 330 feet via HDBaseT Technology

Back Up Power Supply & Unbundled Receivers

Make An Offer Below

Order Information
Part No.:AT-PRO2HD88M
Pick HDMI Extender over single CAT5e/6/7:
Pick HDMI oHDMI Extender over Single CAT5e/6/7 w/Audio De-embedding:
Price:$7,499.95
Availability:Usually ships the same business day
   Quantity:


This Atlona 8x8 Professional HDMI Matrix Switcher over CAT5/CAT6 & HDBaseT routes HDMI video + multi-channel (up to 7.1-channel) audio from any of the eight HDMI sources to the 8 remote displays. Because it is a matrix switcher, it allows any input to be routed to any output; or the same input to be routed to all outputs or any combination.

8x8 HDMI Matrix Switcher with 3D Support Features:

  • HDMI 1.3 compliant
  • HDBaseT technology
  • HDCP compliant
  • Supports high resolution up to 1920x1200 or 1080p
  • Allows any source to be displayed on multiple displays at the same time
  • Allows any HDMI display to view any source at any time
  • Supports all HDMI formats including latest Dolby TrueHD and DTS-HD
  • Supports default HDMI EDID and records the EDID from all 8 displays
  • Main matrix center can be switched with IR remote control, through RS-232 or manual push-in buttons
  • Allows to control Local video sources such as DVD, TiVo, Cable Box or any other by IR extender (each Cat5/Cat6 Receiver unit has an IR blaster)
  • Allows to control main matrix center through control line at remote receiver
  • Extends 1080p signal up to 330ft (cat5/cat5e) or 150ft (cat6)
  • Each display's input source can be switched with IR remote control or push button through control line at remote receiver
  • Rack Mountable (comes with rack ears)
  • Control4, RTI, Crestron, AMX compatible
  • Easy installation
Through low cost Cat5 or Cat6 LAN cables, not only high quality video (up to 1080p) and audio can be transmitted to the display sites, but also users can switch among 8 HDMI sources using the push button or remote control.

Atlona's OPTIONAL receiver modules are both equipped with bidirectional IR and RS-232, and locking power connectors, and extend HDMI sources up to 330 feet at 1080p resolution that supports all 3D formats. In addition, the AT-PRO21616-RX features built-in audio de-embedding. The AT-PRO2HD88M and AT-PRO2HD1616M have the ability to equalize, amplify, and reclock the signal to ensure HDMI-accurate signal transmission through long cables without quality loss

Go Further with More: Extend your audio/visual experience up to 330ft over CAT5e/6/7 cables. This HDBaseT based technology allows you to send IR, RS-232, video (up to 1080p or 1920x1200) and audio (all Lossy and Lossless formats) signals over a single CAT5e/6/7 cable.

Bidirectional Control: Compatible with all 3rd party controllers and IR remote controls, get bidirectional control from the RS-232 and IR ports. Control the matrix and the in zone displays with RS-232 or control all connected devices with the new zone dedicated IR ports.

No Device Left Behind: Ensure that even the most difficult display can receive audio and video with 8 programmable memory presets loadable to any source connected to the matrix.

Back Up Power Supply: In the event the main power supply becomes inoperable the built in redundant power supply will seamlessly take over the matrices energy needs.

Note: We recommend to use 568B wiring for your Cat5e or Cat6 cables Since it is high definition video we only recommend CAT5/6 cables with specs like our CAT-5 /6 cables either bought from us or another high quality supplier. We also recommend, if possible, pre-made cables that are factory tested vs. field made cables due to the advanced testing methods used.

Why not buy this 8x8 HDMI Matrix Switcher with HDBaseT support today?




The matrix switchers feature stereo pass-through to allow the routing of local source audio from the matrix head-end to zone receiver units. Supporting bidirectional RS-232 and IR makes the units ideal for control and automation solutions such as Control4, RTI, and all other control systems.

In addition, the matrix switchers provide support for Deep Color, HDCP, as well as full 3D support for all formats, while preserving 7.1-channel digital audio, including DTS-HD and Dolby(R) TrueHD. For portability and rack-mount installations, the AT-PRO2HD88M and AT-PRO2HD1616M are available with four convenient U rack ears attached.

8x8 HDMI Matrix Switcher with HDBaseT Specs:

  • Bandwidth Frequency: 6.75Gbps
  • Input ports: 8 x HDMI (Female Type), 9 x IR 3.5mm mono, 1 x Firmware update, 8 x 3.5mm Stereo Audio
  • Output ports: 8 x CAT 5e/6/7, 1 x RS-232, 9 x IR 3.5mm mono
  • Resolution outputs: Video: up to 1080p Vesa: up to 1920x1200
  • Dimensions (HxWxD): 6.93x18.98x14.27 (inch) or 176x482x362.5 (mm)
  • Weight: 21.61lbs or 9.8 kg

8x8 HDMI Matrix Switcher with HDBaseT Package Contents

  • 1 x 8x8 Matrix Switcher over CAT5e/6/7
  • 9 x IR Extender
  • 9 x IR Emitter
  • 2 x 24V/6.25A DC adaptor
  • 2 x Power Cord
  • 1 x Remote Control
  • 1 x User Manual

The Atlona AT-PRO2HD88M is an 8x8 high-speed HDMI matrix switcher that makes use of HDBaseT technology to allow signal runs up to 100 meters. The switcher is a solution for larger residential multi-room A/V projects where multiple signals must be sent through a single Cat 5 cable to feed up to eight separate receiver modules.

This 8x8 HDMI Matrix Switcher with HDBaseT works with the following devices:

  1. Any high definition Dish Network and DirecTV receiver with HDMI outputs
  2. High definition TiVo's with HDMI outputs
  3. Any high definition cable receiver with HDMI outputs
  4. Canadian Rogers, Shaw, Bell ExpressVu and Star Choice receivers with HDMI out, or DVI out with a converter
  5. Any "Over The Air" (OTA) high definition receiver with HDMI outputs
  6. Sony PS3, HD DVD and Blu-ray DVD players
  7. Any Xbox360 with HDMI outputs
  8. Any upconverting DVD player with HDMI outputs
  9. Any DVHS VCR with HDMI outputs
  10. An APPLE TV with HDMI outputs
  11. A VuDu with HDMI outputs
  12. Many PC video cards with HDMI outputs
  13. Any high definition camcorder with an optional type C to standard HDMI cable
  14. Many A/V surround sound receivers with HDMI switching that include the proper chip set. Call your AV receiver supplier to discuss your application or us.
  15. Any HDCP compliant HDTV, monitor and projector. If the source is HDCP compliant and your TV is not, you will not get a picture. Please check your TV manual or the manufacturers web site.
  16. and other similar devices.


One refurbished unit available for only $3499.95 plus shipping - Call in your order today at 800-841-9238 or place it above as only 1 left.

AT-PRO2HD88Mhttp://www.hdtvsupply.com/8x8-hdmi-matrix-switcher.html$7,499.95

HDTV Supply has this in stock in our California warehouse so place your order at the above ADD TO CART button by 11AM PST and it can ship today or call us at 800-841-9238 to place your order. It is similar to their 8x8 matrix switch.



HDTV Supply has this in stock in our California warehouse so place your order at the above ADD TO CART button by 11AM PST and it can ship today or call us at 800-841-9238 to place your order.


3 Year Limited Warranty: Atlona Technologies warrants that (a) its products (the “Product”) will perform substantially in accordance with the accompanying written materials for a period of 3 years from the date of receipt and (b) that the Product will be free from defects in materials & workmanship under normal use & service for a period of 3 years. In the event applicable law imposes any implied warranties, the implied warranty period is limited to 3 years from the date of receipt. Some jurisdictions do not allow such limitations on duration of an implied warranty, so the above limitation may not apply to Customer. For more info see Atlona 3-year Warranty Terms and Conditions.

Atlona 3 Year Warranty Terms and Conditions: In order to get a warranty replacement for a defective item, HDTV Supply's and Atlona Support Team must verify the product is eligible for warranty. A warranty number will then be issued to the customer along with the Warranty Form. Both the Warranty Number and the Warranty Form must be completely filled out printed and shipped along with the product. Shipped replacements for Warranty, will be in like new conditions, tested and all components included.

Product Registration: Please register your product along with its serial number at Atlona Product Registration upon receiving the product.
